Category: Box PC, Edge Computer
Tags: Expandable J1900 box PC
| System Hardware | |||
| Chipset | Intel® Bay-trail J1900 | Watchdog | 0-255 seconds/classification is realized by system software |
| Ram | Standard 2GB DDR3L memory, maximum support 8GB | Power Supply | 9-24V DC input (9-36V wide voltage optional) 10W (standby state) 15W (rated power) |
| Storage | 64GB/128GB/512GB SSD (2.5-inch HDD optional) | Hardware monitor | Voltage and CPU temperature monitoring |
| OS | |||
| OS | Windows 7/8/10、Linux | ||
| I/O Ports | |||
| USB | 5*USB 2.0+1*USB 3.0 | Display | 1*VGA +1*HD |
| COM | 6*RS232 (1-2 RS485/RS422 optional) | GPIO | 4 input/4 output optional (reduce 1 DB9 COM) |
| Ethernet | 2* Intel® I211 Gigabit Network Interface | MiniPCIE | 1*MINI PCIe(WIFI/BT or 4G) |
| Audio | 1*Line-out+1*MIC-in | ||
| Environment | |||
| Vibration Protection | 5-19Hz/1.0mm amplitude 19-200Hz/1.0g acceleration | Operating Temp. | -20℃～60℃, with air flow |
| Shock Protection | acceleration 10g/11ms | Storage Temp. | -40℃～70℃ |
| Reliability | MTBF≥50000h; MTTR≤0.5h | Humidity | 95% @40℃, non-condensing |
| Mechanical | |||
| Dimension (LxWxH) | 211.5mm*200mm*67mm | Material | Aluminum alloy fanless design |
| Weight | 2.44kg/4.0kg(N.W/G.W) | Color | Black |
