Category: Rugged Tablet, Windows Rugged Tablet
| System Hardware | |||
| CPU | Intel® Cherry Trail Quad-core Z8350 1.44GHZ~1.92GHz | MIC | Waterproof MIC |
| Memory | 4GB | Button | Power button, Volume +/-, 1*Barcode scanner shortcut key |
| Storage | 64GB | LED Indicator | Charging indicator |
| Camera | 2MP front camera with fixed focus 5MP rear camera with auto focus | Sensor | Gsensor |
| Speaker | Single speaker, 1W/8Ω | ||
| Display | |||
| LCD Type | 8" TFT-LCD | Luminance | 500 cd/m2, Optional 700/1000 cd/m2 |
| Max. Resoltuion | 800x1280 | Touchscreen | 5-Points projected capacitive touchscreen, up to 10-points |
| Cover Glass | Corning Gorilla Glass III, hardness 7H, light transmittance 85% | ||
| OS | |||
| OS | Windows 10 | ||
| I/O Interface | |||
| POGO PIN | 1*POGO PIN(USB+Charging) | DC Jack | 1*DC Jack |
| USB | 1*USB Type C(USB OTG+Charging)1*USB 2.0, TYPE A | SIM Card Slot | 1*Micro SIM Card Slot |
| Video | 1*mini HD | TF Card Slot | 1*TF Card Slot, up to 1T |
| Audio | 3.5mm Headphone Jack | Aviation Plug | Expansion 1*RS232 or 1*DC or 1*Ethernet port (100M) or 1*USB2.0 |
| Communication | |||
| WWAN | EC-25EC (Europe/Middle East/Africa/Korea/Thailand)LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 | WIFI | 802.11a/b/g/n/ac, 2.4G+5.2G Dual-band WIFI |
| Bluetooth | Bluetooth 4.0 (BLE) | ||
| GNSS | U-blox GPS+BeiDou+GLONASS | ||
| Extended Functions | |||
| NFC/RFID | Optional NFC/HF-RFID/UHF-RFID, 3 choose 1 | Barcode Scanner | Optional 1D/2D barcode scanner, 2 choose 1 |
| Fingerprint | Optional fingerprint recognition | ||
| Power | |||
| Power Input | 5V DC Input, 5V/3A power adapter Optional 5～24V DC power input, no built-in battery power supply | Battery | 9800mAh, 3.8V Li-Ion battery |
| Battery Life | 8 hours (Play 1080P video under LCD 50% backlight) | ||
| Environment | |||
| Drop | 1.2m free fall to the wooden floor | Operating Temp. | -10℃~50℃ |
| IP Rating | Standard IP65, optional IP67 | Storage Temp. | -30℃~70℃ (excluding batteries) |
| Certificate | |||
| Certificate | CE、ROHS、UN38.3、MSDS | ||
| Mechanical | |||
| Dimension (W x H x D) | 227*142.4*22.9mm Optional UHF RFID module, thickness increases 9.5mm | Weight | 0.80kg |
| Color | Black | ||
| Accessory | |||
| Accessory | Hand strap, Type-C OTG cable, 5V/3A power adapter | ||
| Optional Accessory | Docking, Vehicle bracket, Vehicle charger, Passive touch pen, Type-C data cable, Vehicle charging bracket | ||
