Category: Panel PC, Vehicle Mount Computer
| System Hardware | |||
| CPU | RK3288 SoC Cortex-A17 Quad Core @ 1.8GHz Max. | Storage | EMMC 8GB/16GB/32GB optional (default 8GB), compatible with NAND Flash |
| Memory | DDR3 onboard 2GB, optional 4GB | ||
| Display | |||
| LCD Type | 7″ RGB TFT industrial display | Luminance | 400 cd/m2 |
| Max. Resoltuion | 1280*800 | Touchscreen | Multi-touch capacitive screen |
| OS | |||
| OS | Android 5.1 and above | ||
| I/O Ports | |||
| USB | 2*USB 2.0 | WIFI/BT | Single/dual frequency WIFI+BT4.0 (external antenna) |
| Serial port | 2*RS232 | TF card | 1*TF card holder, maximum support 64GB |
| Network port | 1 RJ45 Gigabit Ethernet port | SIM card | 1*SIM card holder |
| Audio | 1*Audio | Expand | 1*Mini PCIe (3G/4G optional) |
| Show | 1*HD | GPIO | 4*GPIO (occupies a DB9 interface) |
| Power | |||
| power supply | 12V DC input, Power consumption 8W | ||
| Environment | |||
| Operating Temp. | -10℃～60℃ , with air flow | Shock Protection | acceleration 10g/11ms |
| Storage Temp. | -20℃～70℃ | Vibration Protection | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration |
| Humidity | 95% @40℃, non-condensing | ||
| Mechanical | |||
| Dimension (WxHxD) | 186*135*45.5mm | Color | Black |
| Weight | 1kg/1.7kg (N.W./G.W.) | Material | High-strength aluminum alloy, fanless design |
