As industrial automation continues to evolve, businesses require reliable computing equipment that can operate efficiently in demanding environments without increasing operational costs. The 12.1 Inch Economy Capacitive Panel PC is designed to meet these requirements by combining stable performance, industrial durability, and flexible integration into one compact solution.
Powered by Intel® 11th Gen processors and equipped with a responsive multi-point capacitive touchscreen, this industrial panel PC delivers smooth operation for factory automation, warehouse management, transportation systems, and smart monitoring applications. Built with an all-metal structure and an IP65-rated front panel, it is engineered to withstand challenging industrial conditions while maintaining consistent performance over long periods of operation.
| System Hardware | |||
| CPU |
Intel® Processor Core™ 11th Gen i3/i5/i7 |
Memory |
1*DDR4 8GB (optional 16/32GB) |
| Watchdog |
0-255 seconds/grading implemented through system software |
Storage |
Optional 128GB-1T M.2 2280 SATA SSD |
| Display | |||
| LCD Type |
12.1″ |
Luminance |
500 cd/m2 |
| Max. Resolution |
1280*800 |
Screen lifespan |
50000h |
| Touch Screen | |||
| Touch Screen |
12.1 "multi-point capacitive touch screen |
hardness |
6H |
| light transmission |
＞85% |
||
| OS | |||
| OS |
Win10,Win11,Linux | ||
| I/O Ports | |||
| USB |
6*USB3.0 |
Audio |
2 in 1 Audio |
| Serial port |
4*RS232(Optional 1-4*RS485/422) |
Video |
1*HDMI+1*VGA |
| LAN |
2*100/1000M |
Expansion Slot |
Optional dual band WiFi+BT or 4G |
| Power | |||
| Power Input |
Standard Phoenix terminal 2pin input, supports 9-36V wide voltage | ||
| Environment | |||
| Vibration Protection |
5-19Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration |
Operating Temp. |
-10℃～60℃, Surface air flow |
| Shock Protection Reliability |
10g acceleration, 11ms cycle MTBF ≥ 30000h; MTTR ≤ 0.5h |
Storage Temp. |
-20 ℃~70 ℃ |
| Humidity |
95% @ 40℃, no condensation |
IP Rating |
Front panel IP65 |
| Mechanical | |||
| Dimension (WxHxD) | 316mm*218mm*61mm |
Material |
All metal fanless design |
| Weight | 3.5kg/4kg(N.W./G.W.) |
Mounting | VESA Installation: 100*100mm Embedded Installation: 302mm*204mm |
| Color |
Black |
||
| Ordering Information: | |||
| Serial Number |
Model |
CPU |
Notes |
| 1 | TY121-GS113AH |
i3-1115G4 |
The CPU may change based on the market Please consult the sales for the specific CPU before placing the order |
| 2 | TY121-GS115AH |
i5-1135G7/1155G7 | |
| 3 | TY121-GS117AH |
i7-1165G7 | |
