Category: Rugged Tablet, Windows Rugged Tablet
| System Hardware | |||
| CPU | Intel® Cherry Trail Quad-core Z8350 1.44GHZ~1.92GHz |
MIC |
Dual MIC |
| Memory | 4GB |
Button |
Power button, Volume +/-, Barcode scanner shortcut key |
| Storage |
64GB |
LED Indicator |
charging indicator |
| Camera |
2MP front camera with fixed focus 5MP rear camera with auto focus |
Sensor |
Gsensor |
| Speaker |
Dual speaker, 1W/8Ω |
||
| Display | |||
| LCD Type | 10.1" TFT-LCD | Touchscreen |
Five-point capacitive touchscreen, up to ten-point; AG+AF coating optional |
| Max. Resoltuion |
800*1280, Optional 1200*1920 800cd/㎡ |
Cover Glass | Corning Gorilla Glass III, hardness 7H, light transmittance 85% |
| Luminance |
450 cd/m2, Optional 1000 cd/m2 (800*1280) |
||
| OS | |||
| OS | Windows 10 |
||
| I/O Interface | |||
| POGO PIN | 1*POGO PIN(USB+Charging) |
LAN |
1*RJ45 |
| USB | 1*USB Type C(USB OTG+Charging) 1*USB 2.0, TYPE A |
COM Port |
1*RS232 |
| Video |
1*mini HD |
SIM Card Slot |
1*Micro SIM card holder |
| Audio | 3.5mm headphone jack | TF Card Slot | 1*TF Card Slot, up to 1T |
| DC Jack |
1*DC Jack | Aviation Plug | Expand 1 * RS232 or 1 * DC or 1 * Ethernet port (100M) or 1 * USB 2.0 |
| Network Communication | |||
| WWAN | EC-25EC (Europe/Middle East/ Africa/Korea/Thailand) LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 |
WIFI | 802.11a/b/g/n/ac, 2.4G+5.2G Dual-band WIFI |
| Bluetooth | Bluetooth 4.0 (BLE) | ||
| GNSS | U-blox GPS+BeiDou+GLONASS | ||
| Extended Functions | |||
| NFC | Optional, 13.56MHz, support 14443A/14443B/15693 | ID Card Recognition |
Optional ID card recognition module |
| RFID |
Optional RFID/HF RFID/UHF RFID |
Barcode Scanner | Optional 1D/2D barcode scanner, 2 choose 1 |
| Power | |||
Power Input |
5V DC Input, 5V/3A power adapter |
Battery Life |
8 hours (Play 1080P video under LCD 50% backlight) |
Battery |
10000mAh, removable 3.8V Li-Ion battery |
||
| Environment | |||
| Drop | 1.2m free fall to the wooden floor | ||
| IP Rating | Standard IP67 | ||
| Operating Temp. | -10℃~50℃ | ||
| Storage Temp. | -30℃~70℃ | ||
| Certificate | |||
| Certificate | CE、ROHS、UN38.3、MSDS、IEC62133 | ||
| Mechanical | |||
| Dimension (WxHxD) | 274*181*23mm Optional UHF RFID module, thickness increases 9.5mm |
Weight | 1.25kg |
| Color | Black | ||
| Accessory | |||
| Accessory | Hand strap, 5V/3A power adapter | ||
| Optional Accessory | Office docking, Vehicle stand, Vehicle charger, Passive touch pen, Type-C data cable, Type-C OTG cable, USB-DC cable | ||
