Category: Linux Rugged Tablet, Rugged Tablet
| System Hardware | |||
| CPU | Intel® Celeron® N2930 1.83GHz Porcessor | Memory | Onboard 4GB DDR3 memory |
| Hardware Monitoring | Voltage and CPU temperature monitoring | Storage | Standard 64GB SSD, maximum support 512GB |
| Display | |||
| Display Screen | 10.1″ TFT LCD | Brightness | 350 cd/m2 |
| Touch Screen | 10.1″ Multi-touch capacitive touch screen | Contrast | 800: 1 |
| Resolution | 1280*800 | ||
| OS | |||
| OS | Windows 7/Windows 10/ Linux | ||
| I/O Interface | |||
| Camera | Front 200W, rear 500W | Audio | Built-in speaker, MIC |
| USB | 1*USB 3.0 + 1*USB 2.0 Type A | Video | 1*Mini HD |
| Serial port | 1*DB9 (expandable 2*RS232 or 1*RS485) | SIM card | 1*SIM card slot |
| LAN | 1*Intel® I211AT RJ45 1000M LAN/IEEE 802.11 | TF card | 1*TF card slot |
| Wireless | 2.4/5.8 dual band WiFi | Expand | 3G/4G/5G optional /GPS optional/RFID optional /2D scan code optional |
| BT | 4.0 | ||
| Power | |||
| Power Input | 5400mAh 7.4VLi-ion battery, 12V DC input (standard 12V power adapter) | ||
| Accessories | |||
| Accessories | With capacitive pen (optional hand strap, shoulder strap) | ||
| Environment | |||
| Vibration Protection | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration | Reliability | MTBF≥5000h; MTTR≤0.5h |
| Shock Protection | acceleration 10g/11ms | Operating Temp. | -10℃~50℃ |
| IP protection level | IP65 optional | Storage Temp. | -30℃~70℃ (excluding batteries) |
| Humidity | 95% @40℃, non-condensing | ||
| Mechanical | |||
| Dimension (W x H x D) | 275 *195 *28mm | Material | Aluminum-magnesium alloy |
| Weight | 1.15kg | Color | Coffee gold |
